• LGA 1155 socket for:
- Intel® Core™ i7-2600 (8M Cache, up to 3.8 GHz); 95W
- Intel® Core™ i5-2400 (6M Cache, up to 3.4 GHz); 95W
- Intel® Core™ i3-2120 (3M Cache, 3.3 GHz); 65W
- Intel® Pentium® G850 (3M Cache, 2.9 GHz); 65W
• New microarchitecture on 32nm process technology
• Intel® Advanced Vector Extensions (Intel® AVX) Instructions
• Intel® Turbo Boost Technology
芯片组
• Intel® Q67 PCH (Platform Controller Hub)
系统内存
• Four 240-pin DDR3 DIMM sockets
• Supports DDR3 1066/1333MHz
• Supports dual channel memory interface
• Supports up to 32GB system memory
• DRAM device technologies: 1Gb, 2Gb and 4Gb DDR3 DRAM technologies are supported for x8 and x16 devices, unbuffered, non-ECC
• Intel® HD Graphics
• Display ports: DVI-I (DVI-D signal) and VGA
• DVI-I supports up to 1920x1200 @ 60Hz resolution
• VGA supports up to 2048x1536 @ 75Hz resolution
• Supports 6 Graphics Execution Units (EUs)
• Intel® Clear Video Technology
• DirectX Video Acceleration (DXVA) support for accelerating video processing
声卡
• Realtek® ALC886 5.1-channel High Definition Audio
• Audio outputs: Mic-in/Center+Subwoofer, line-in/surround and line out
• S/PDIF audio interface
• 6 Serial ATA ports
- 4 SATA 2.0 ports with data transfer rate up to 3Gb/s (SATA port 4 provides adequate space for SATA DOM)
- 2 SATA 3.0 ports with data transfer rate up to 6Gb/s
• Integrated Advanced Host Controller Interface (AHCI) controller
• Supports RAID 0/1/5/10
主动式管理技术
• Supports iAMT7.0
• Out-of-band system access
• Remote troubleshooting and recovery
• Hardware-based agent presence checking
• Proactive alerting
• Remote hardware and software asset tracking
可信任平台模块（选配）
• Provides a Trusted PC for secure transactions
• Provides software license protection, enforcement and password protection
后面板输出/输入端口
• 1 mini-DIN-6 port for PS/2 mouse/keyboard
• 2 DB-9 serial ports
- Supports RS232/422/485 (RS232 and/or Power)
• 1 DB-15 VGA port
• 1 DVI-I port (DVI-D signal)
• 2 RJ45 LAN ports
• 6 USB 2.0/1.1 ports
• Line-in/Surround, Line out, Mic-in/Center+Subwoofer jacks
输入/输出连接器
• 3 connectors for 6 external USB 2.0/1.1 ports
• 4 connectors for 4 external RS232 serial ports
• 1 SDVO connector for optional SDVO-LVDS daughterboard
• 1 8-bit Digital I/O connector
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in connector
• 1 S/PDIF connector
• 6 Serial ATA ports
• 1 IDE connector
• 1 24-pin ATX power connector
• 1 8-pin 12V power connector
• 1 chassis intrusion connector
• 1 front panel connector
• 3 fan connectors
BIOS
• AMI BIOS
- 64Mbit SPI BIOS
节能设计
• Supports ErP Lot6 power saving (optional)
• Supports ACPI
• System Power Management
• Wake-On-Events include:
- Wake-On-PS/2 KB/Mouse
- Wake-On-USB KB/Mouse
- Wake-On-LAN
- RTC timer to power-on the system
• CPU stopped clock control
• AC power failure recovery
智能型零损耗监控
• Monitors CPU/system temperature and overheat alarm
• Monitors VCORE/5V/3.3V/V_DIMM/12V/5VSB voltages and failure alarm
• Monitors CPU/system fan speed and failure alarm
• Read back capability that displays temperature, voltage and fan speed
• Watchdog timer function
