>> System
Processor LGA775 for Core 2 Duo/Pentium D/Celeron processor（Max TDP up to 95W）
Chipset Intel G41 + ICH7, FSB 800/1066/1333MHz
DRAM 2 x 240PIN DIMM DDR3 800/1066 max up to 8GB
BIOS 8Mb AMI Flash ROM
Power Supply 1 x 20Pin ATX power connector, support AT/ATX mode
Watchdog Watchdog timer function
Dimension 170mm x 170mm
>> I/O Ports
HDD 2 x SATA-300 Interface,1 x 44pin IDE Interface;
Serial Port 4 x COM ports (4*RS232)
Parallel 1 x Parallel pin-header
Audio Realtek ALC662 HD audio codec, support 5.1CH audio
Keyboard/Mouse 2 x PS/2 for Keyboard and Mouse
LAN 2 x Realtek RTL8111E PCI-E Gigabit Lan
USB 8 x USB2.0 (4 by onboard header)
Digital I/O 4 input; 4 output
Expansion 1 x PCI slot Expansion
>> Display
Graphics Intel GMA X4500 up to 1024MB video memory
VGA 2048 x 1536 maximum resolution
>> Environment
Operation Temperature 0°~60°C
Humidity 10~90%
