产品标准
处理器
LGA 1150 socket for:
- 4th Generation Intel® Core™ processors
 (22nm process technology)
  : Intel® Core™ i7-4770S (8M Cache, up to 3.9 GHz); 65W
  : Intel® Core™ i7-4770TE (8M Cache, up to 3.3 GHz); 45W
  : Intel® Core™ i5-4570S (6M Cache, up to 3.6 GHz); 65W
  : Intel® Core™ i5-4570TE (4M Cache, up to 3.3 GHz); 35W
  : Intel® Core™ i3-4330 (4M Cache, 3.5 GHz); 54W
  : Intel® Core™ i3-4330TE (4M Cache, 2.4 GHz); 35W
  : Intel® Pentium® G3420 (3M Cache, 3.2 GHz); 53W
  : Intel® Pentium® G3320TE (3M Cache, 2.3 GHz); 35W
芯片组
Intel® H81 Express Chipset
系统内存
Two 204-pin DDR3/DDR3L SODIMM sockets
Supports DDR3/DDR3L 1333/1600MHz
Supports up to 16GB system memory
Supports dual channel memory interface
DRAM device technologies: 1Gb, 2Gb and 4Gb DDR3 DRAM technologies are supported for x8 and x16 devices, unbuffered, non-ECC
扩展插槽
1 PCIe x16 Gen 3 slot (PCIe 2.0)
1 Mini PCIe slot
- Supports USB and PCIe signals
- Supports mSATA
- Supports full size Mini PCIe card
显示
Intel® HD Graphics
Display ports: HDMI, DVI-I, LVDS
HDMI, DVI-I: resolution up to 1920x1200 @ 60Hz
LVDS: 24-bit, dual channel, resolution up to 1920x1200 @ 60Hz
Supports 20 Graphics Execution Units (EUs)
Intel® Clear Video Technology
DirectX Video Acceleration (DXVA) support for accelerating video processing
声卡
Realtek ALC886 5.1-channel High Definition Audio
S/PDIF audio interface
网络
Intel® I210 PCI Express Gigabit Ethernet controller
Intel® I217 Gigabit Ethernet Phy
Integrated 10/100/1000 transceiver
Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
SATA界面
2 SATA 3.0 ports with data transfer rate up to 6Gb/s
后面板输出/输入端口
1 mini-DIN-6 PS/2 keyboard/mouse port
4 USB 2.0 ports
2 USB 3.0 ports
2 DB-9 RS232 serial ports
1 HDMI port
1 DVI-I port
2 RJ45 LAN ports
Mic-in, line-in and line-out jacks
输入/输出连接器
1 connector for 2 external USB 2.0/1.1 ports
1 LVDS LCD panel connector
1 LCD/inverter power connector
1 8-bit Digital I/O connector
1 Digital I/O power connector
1 front audio connector for line-out and mic-in jacks
1 S/PDIF connector
1 LPC connector (optional)
2 SATA 3.0 ports
1 24-pin ATX power connector
1 4-pin 12V power connector
1 chassis intrusion connector
1 front panel connector
2 fan connectors
可信任平台模块（选配）
Provides a Trusted PC for secure transactions
Provides software license protection, enforcement and password protection
BIOS
AMI BIOS
- 64Mbit SPI BIOS
节能设计
Supports ErP Lot6 power saving (optional)
Supports ACPI
System Power Management
Wake-On-Events include:
- Wake-On-PS/2 KB/Mouse
- Wake-On-USB KB/Mouse
- Wake-On-LAN
- RTC timer to power-on the system
CPU stopped clock control
AC power failure recovery
 智能型零损耗监控
Monitors CPU/system temperature and overheat alarm
Monitors VCORE/5V/3.3V/V_DIMM/12V/5VSB voltages and failure alarm
Monitors CPU/system fan speed and failure alarm
Read back capability that displays temperature, voltage and fan speed
Watchdog timer function
 POWER CONSUMPTION
TDB
OS SUPPORT
Windows XP Professional x86 & SP3 (32-bit)
Windows XP Professional x64 & SP2 (64-bit)
Windows 7 Ultimate x86 & SP1 (32-bit)
Windows 7 Ultimate x64 & SP1 (64-bit)
Windows 8 Enterprise x86 (32-bit)
Windows 8 Enterprise x64 (64-bit)
(based on Intel's Windows XP support list)
溫度
Operating: 0°C to 60°C
Storage: -20°C to 85°C
湿度
10% to 90%
尺寸
Mini-ITX form factor
170mm (6.7") x 170mm (6.7")
认证
CE, FCC Class B, RoHS, UL
